Machine tool industry lathe, milling machine, drilling center, CNC machining center, etc
Installation mode：
embedded installation
Texture of material：
Customize or select standard products on demand
Input voltage：
other customized
Communication mode：
RS485/RS422
Protection grade：
IP65
Size：
customized according to customer requirements
Support customization：
Design the overall dimension, key layout and quantity according to customer requirements
Key value：
customized
Key life：
1 million times
Working temperature：
-20℃ ~+75℃
Storage temperature：
-40℃ ~+85℃
Ambient humidity：
5% ~ 90% (non condensing)
Surge：
±2KV
Pulse group：
2KV（5K~100K）
Contact discharge：
±4KV
Air discharge：
±8KV
Screen：
It supports 10-21.5-inch capacitance screen, resistance value and other gauge screens, and can be displayed in dual screens“
Host：
Flexible configuration according to customer requirements, optional all aluminum fanless PC
PC keyboard：
Injection molding keys
Custom keyboard：
"Any number of key values can be defined According to the definition of customer requirements, the output combination key value can be triggered by one key"
Output port：
Decchi 4Pin
language：
Customize various language versions
Trigger mode：
microswitch
Function developmen：
According to the appearance size and communication mode required by users
